| Hình thức thanh toán: | T/T |
| Incoterm: | FOB,CFR,CIF,EXW,FCA |
| Đặt hàng tối thiểu: | 1 |
| Giao thông vận tải: | Ocean,Land,Air |
| Hải cảng: | ningbo,shanghai,guangzhou |
Mẫu số: NBESRA300 - 000
Thương hiệu: Cơ sở mới
Loài: Van
Nhiên Liệu: Điện
Gốc: Trung Quốc
Applicable Compartment Volume: 7 - 10m³
Minimum Compartment Temperature: -20℃
Refrigerating Capacity: 3200W at 0℃/30℃ 1850W at -20℃/30℃
High Voltage: DC250V - DC450V (Low Voltage Platform) DC380V - DC750V (High Voltage Platform)
Power: 2500W at 0℃/+30℃ 1300W at -20℃/+30℃
Driving Mode: Pure Electric
Control Voltage: DC12V (9 ~ 16V) DC24V (16 ~ 32V)
Low - Voltage Power Supply: DC - DC Self - supply / or Connect to the Whole Vehicle
Standby Power Supply: AC220V/380V (Optional)
Máy Nén: Quảng Châu Guangyu gy27.e72 - 601c (biến tần)
Chất Làm Lạnh: R404A
Điện Tích Làm Lạnh: 1,2kg
Phương Pháp Rã đông: Tự động rã đông khí nóng
Phương Pháp Sưởi ấm: Nóng khí nóng / PTC (tùy chọn)
Phương Pháp Kiểm Soát: Có thể giao tiếp
Lắp Ráp Ngưng Tụ: Kích thước (l*w*h) (mm): 740*730*468, trọng lượng (kg): 75
Quạt Ngưng Tụ: Số lượng (PC): 1, Tổng thể tích không khí (M³/H): 1800
Lắp Ráp Thiết Bị Bay Hơi: Kích thước (l*w*h) (mm): 1038*570*140, trọng lượng (kg): 22
Quạt Bay Hơi: Số lượng (PC): 2, Tổng thể tích không khí (M³/H): 2000
| Loại gói hàng | : | Thùng carton và hộp gỗ |
| Ví dụ về Ảnh | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
| Aspect | Our New Energy Smart Cold Chain Solution | Traditional Fuel-Powered Alternatives |
| Product Type | Versatile fleet: from Mini Refrigerated Van (city delivery) to small chiller truck (pharmaceutical) and freezer truck mini (meat/seafood), even adaptable to Refrigerated Tricycle for ultra-niche last-mile needs | Single-function, low flexibility |
| Temperature Control | -20℃ to +25℃ wide range, ±0.5℃ precision—ideal for light duty refrigerated vehicle demands in pharma and F&B | Narrow range, inconsistent performance |
| Regional Adaptation | Engineered for Saudi’s -30℃ to +50℃ extremes and UAE’s urban chaos (Newbase reefer van Dubai agility) | Prone to failure in Middle East’s harsh climates |
| Intelligence | IoT-enabled tracking (temperature, GPS, compliance) | Basic or no smart monitoring |
| cenario | Middle East-Specific Pain Points | Our Solution | Value Creation |
| Pharmaceutical Cold Chain (KSA) | Vaccine spoilage in 50℃ heat; non-compliance with GCC regulations | With -18℃ ±0.5℃ control + GSP-certified IoT | 100% compliant vaccine/biologic transport |
| Meat/Seafood Delivery (Kuwait/Saudi) | Frozen cargo thawing during long-haul trips | With -20℃ freeze capability + solar-powered endurance | Zero spoilage in high-temp regions |
| Urban Grocery Runs (UAE) | Narrow streets + time-sensitive delivery | With compact design + 20min quick-cooling | Efficient last-mile delivery in Dubai/Abu Dhabi |
